PARAMETER

SPECIFICATION

DISPLAY

Screen size

177.8 mm (7 in.), measured diagonally

Screen type

TFT LCD, white LED backlight, viewing cone of 60° and optimal viewing distance of 1.5 meter

Resolution

800 x 480 pixels

ECG

Measurement range

25bpm to 350bpm

Lead selection

I,II, III,V, aVF,aVL,aVR

Display gain

X1/4, X1/2, X1, X2, X4

Didplay sweep speed

6.25mm/s,12.5mm/s,25mm/s,50mm/s

Accuracy

±2BPM or ±2% (whichever is greater)

Resolution

1BPM

NIBP

Method

Oscillometric

Measurement range

0-300mmHg

Accuracy

Based on ANSI/AAMI SP10:1992 and 2002 Standards

Measurement time

30 to 50s typical , 180s maximum

AUTO interval times

2, 3, 5, 10, 30 min, or 1, 2 h

TEMPERATURE

Measuring range

0-50°

Accuracy

±0.2°C

Resolution

0.1°C

SPO2

Range

1%-100%

Accuracy

70-100% (±2% ),<70% undefined

Resolution

1%

Display sweep speed

10.00 mm/sec

PULSE RATE

Measurement range

25bpm to 350bpm

Accuracy

±2 bpm / ±2% (take maximum)

Resolution

1bpm

RESPIRATION

Measurement range

0-130rpm

Accuracy

±1rpm

Resolution

1rpm

SIDESTREAM ETCO2 (OPTIONAL)

Range

0-150mmHg

Accuracy

0-40mmHg (±2mmHg); 41-150mmHg (±10% of reading)

Resolution

0.1mmHg

Flow rate

50 ml/min ±10 ml/min

ELECTRICAL

Battery

Four new lithium batteries with 4,400mAh will typically provide 4.5 hours of monitoring with no external communication, no audible alarm sound, and at an ambient temperature of 25°C

Type

Lithium Batteries, 4,400mAh, DC 11.1V

Voltage

AC 100-240V, 50-60Hz, 80VA

ENVIRONMENTAL

Temperature

Transport and storage

-40°C to 75°C (-40°F to 167°F)

Humidity

Operating conditions

0°C to 50°C (32°F to 122°F)

Altitude

-500 to 5,000 m (-1,640 to 16,404 ft.)

Relative humidity

15% to 95% noncondensing

TREND

Memory

Saves a total of 120 hours of data events; saves date and time, alarm conditions, measurements

Tabular format

One table for all parameters

ALARMS

Categories

Patient status and system status

Priorities

Low, medium, and high

Notification

Audible and visual

Setting

Full storage, low battery and sensor off

Alarm volume level

45 to 85 decibels

Alarm system delay

< 10 seconds

DIMENSION AND WEIGHT

Weight

2.05kg (4.52 lb), including 1 battery

Dimensions

324mmW *129mmH*183mmD (12.76in.W x 5.08in.H x 7.20in.D)

CONFIGURATION

Standard

SpO2 + ECG + NIBP + RESP + TEMP

Optional

1. SpO2;

2. SpO2 + NIBP;

3. SpO2 + NIBP + ECG; SpO2 + NIBP + TEMP;

4. SpO2 + ECG + NIBP + RESP + TEMP + ETCO2 etc.;

5. Lithium Battery

6. Trolley

7. Brace

8. IPMS8600 Central monitoring system
