VICU-02 PET ICU Incubator

VICU-02

PET ICU Incubator

VICU-02 PET ICU Incubator

product description

Introduction

VICU-02 PET ICU Incubator is an advanced medical equipment mainly used to provide comprehensive medical care for pets.It has multiple functions, including constant temperature, constant oxygen, negative ion purification, nebulization therapy, blue light therapy, and ultraviolet sterilization. Suitable for various scenarios such as temperature resuscitation, infusion, oxygen therapy, blue light nebulization, rescue, hospitalization observation, etc. for patients, critically ill, and weak animals.



Product Features

  1. 24/7 monitoring:Real time monitoring is carried out through monitoring equipment to ensure the safety and stability of treatment.
  2. CO2 emission:When the CO2 index reaches a certain value, it will automatically start discharging.
  3. Aseptic therapy:High oxygen aseptic therapy, infrared therapy, to enhance treatment effectiveness.
  4. Constant temperature and humidity:creating a stable temperature and humidity environment, providing a comfortable treatment and rehabilitation environment.
  5. Multiple purification:negative ion purification and ultraviolet disinfection to prevent cross infection.
  6. Easy to operate: Simplified operation process, easy to use and manage.
  7. Durable materials: Choose durable materials, reject inferior materials, and ensure stability and safety.



Clinical Indications

  1. Serious respiratory system diseases: pneumonia, asthma, acute respiratory distress syndrome, etc.
  2. Cardiovascular system diseases:myocarditis, cardiomyopathy, heart failure, arrhythmia, etc.
  3. Neurological disorders: encephalitis, concussion, spinal cord injury, etc.
  4. Digestive system diseases: pancreatitis, hepatitis, gastrointestinal bleeding, etc.
  5. Surgical procedures: complex surgeries, organ transplant surgeries, and animals with postoperative complications.
  6. Endocrine system diseases: diabetes, hypothyroidism or adrenal insufficiency.
  7. Urinary system diseases: acute renal failure, uremia, etc.
  8. Hematological system diseases: anemia, leukemia, etc.
  9. Other diseases: severe trauma, poisoning, immune system disorders, etc



Technical Specifications

PARAMETER

SPECIFICATION

External dimension

L1200 x D650 x H1720mm

Weight

220KG

Monitor

W171XH128mm

Touch screen

Pointer membrane resistance type

Power supply

AC100V/220V  50/60HZ (with grounding)

Max power consumption

1.6kw

Average power consumption

0.8kw

Power outage guarantee

With program control emergency ventilation hatch

Air conditioning method

Independent split refrigeration/ PTC heating

Greening air function

UV sterilization lamp; High concentration negative ion air purification

Usage conditions

Indoor environment at -10-40 ° C

Setting temperature

Temperature control accuracy of 16-38 ° C ;Soil 0.5 ° C

Set oxygen concentration

21~60%, control accuracy ±1%

Carbon dioxide concentration

monitor and clear

300-5000PPM, Error margin of 10PPM, Built in medical CO2 high

efficiency purification agent and automatic CO2 removal device

Alert and warning

Abnormal O2 concentration/abnormal temperature/abnormal sensor

and CO2 concentration/abnormal emergency hatch switch, etc

Dehumidification index

Automatic dehumidification system,

The standard humidity is controlled within 40%, actual humidity control is less than 50%.

Divided into three levels: High/ Middle/Low

High: 45%~50% /Middle: 40%-44%/ Low:30%~39%

Negative ion medical purification function

(7.2X10Pcs/cm3X4) High concentration negative ions

Standard accessories

Infusion stand

Micro printer

Intelligent automatic timed printing system

UV sterilization

UVC band 253nm ,efficient UV sterilization system

Blue light medical system

Blue 415nm LED

Medical nebulizer

Maximum atomization rate=0.2ml/min,

Mist particles (0-5-2um)

Noise ≤40dB (A)

Medical Nebulizer LED lighting board

Two way lighting control: warm light adjustable control with ten levels of strength and weakness,

Medical special cold light lamp for medical examination

Fan control

Ventilation volume adjustment

LOW/MIDDLE/HIGH three level input speed regulation

Oxygen input adjustment – low level

Temperature regulation – high level

Emergency ventilation start – high level

UV sterilization – mid range

High CO2 concentration – high end



Configuration Table

-8.4inch touch color screen

-Unmanned power outage protection

-Independent split type refrigeration

-PTC heating

-Purification of high concentration negativ ions

-Intelligent automated printer

-UVC ultraviolet sterilzation

-Open oxygen transfer

-Intelligent control power supply

-Uninterruptible power supply

-Circulation ven

-Medical examination lamp

-Simulated ecological sunlight lamp

-Medical blue light

-Emergency ventilation switch

-Emergency operation window

-CO2 purification

-CO2 alarm

-3D constant oxygen

-Air pressure atomization

-Infusion stand

-Sleeping curtain

-Sodium lime

-Medical nebulizer

-Medical oxygen hose

-High flow oxygen genrator (optional)
