product description
Features
-Windows operation interface, figure button, mouse operation
-96-well plate, multiple tests in the single plate
-Arrangement of Test item in Micro-plate can be store and re-use
-Plate shaking, speed and time adjustable
-Open system, test item and parameters can be added or modified.
-Large storage for 1000 test item and 1,000,000 results
-Printing comprehensive report,include hosiptal and patient information and test results
-External computer, easy to use.
Technical Specifications
|
PARAMETER |
SPECIFICATION |
|
|
Microplate types |
96-well plate(U,V,or plat-bottom) |
|
|
Test mode |
End-point, Kinetic, Multi-wave analysis |
|
|
Wavelength |
405、450、492、630nm, 4 more filters optional |
|
|
Measurement range |
0-4.00Abs |
|
|
Light source |
Tungsten Halogen,12V/20W,>2000 hours |
|
|
Measuring system |
8-channel optical system |
|
|
Resolution |
0.001Abs (display),0.0001Abs (Inner counting) |
|
|
Stability |
<±0.005Abs/10min |
|
|
Sensitivity |
≥0.01L /mg |
|
|
Linearity |
r > 0.999 |
|
|
Repeatability |
< 0.3% |
|
|
Reading speed |
5s single wavelength , 10s double wavelength |
|
|
QC |
West guard Multi-rule, automated QC alert |
|
|
Self-Checking function |
Self-checking and calibration function |
|
|
CPU |
High-speed CPU |
|
|
Printer |
External jet printer, multi-form patient report |
|
|
Interface |
RS232 interface,USB, PSTN and PC connection. |
|
|
Power supply |
220VAC 15% or 110VAC 15%50-60Hz 100W |
|
|
Work environment |
Temp 5°C-40°C；Humi ≤85% |
|
|
Machine Dimension |
43CM*34CM*16CM |
|
|
Weight |
9 KG |
|
